Concealed Hinge

Concealed Hinge

Concealed Hinge 2404-01 Series

SKU: 2404-01

KEY FEATURES

Detachable Installation
Left-Right Interchangeable, Convenient Replacement
Easy Installation With Screws/Nuts
Concealed Installation

MATERIAL

Pin:Q235
Door Part/Frame Part:Q235

Part Number	Installation Mode	Installation Direction
2404-01-L	Screw-On	Left
2404-01-R	Screw-On	Right
2404-11-L	Weld-On	Left
2404-11-R	Weld-On	Right
