Hinge
SKU:
| Part Number | Symmetric Torque (N.m.) | Material | Surface Finish |
|---|---|---|---|
| 2119-B-23-10 | 2.3 | Zinc Alloy | Black Matte Powder Coated |
| 2119-B-39-10 | 3.9 | Zinc Alloy | Black Matte Powder Coated |
| 2119-B-57-10 | 5.7 | Zinc Alloy | Black Matte Powder Coated |
| 2119-B-73-10 | 7.3 | Zinc Alloy | Black Matte Powder Coated |
| 2119-B-90-10 | 9 | Zinc Alloy | Black Matte Powder Coated |
| Part Number | Forward Torque (N.m) | Reverse Torque (N.m.) | Material | Surface Finish |
|---|---|---|---|---|
| 2119-B-1078F-10 | 10.7 | 7.8 | Zinc Alloy | Black Matte Powder Coated |
| 2119-B-1078R-10 | 7.8 | 10.7 | Zinc Alloy | Black Matte Powder Coated |
| 2119-B-1290F-10 | 12.4 | 9 | Zinc Alloy | Black Matte Powder Coated |
| 2119-B-1290R-10 | 9 | 12.4 | Zinc Alloy | Black Matte Powder Coated |
| 2119-B-2317F-10 | 2.3 | 1.7 | Zinc Alloy | Black Matte Powder Coated |
| 2119-B-2317R-10 | 1.7 | 2.3 | Zinc Alloy | Black Matte Powder Coated |
| 2119-B-3930F-10 | 3.9 | 3 | Zinc Alloy | Black Matte Powder Coated |
| 2119-B-3930R-10 | 3 | 3.9 | Zinc Alloy | Black Matte Powder Coated |
| 2119-B-5740F-10 | 5.7 | 4 | Zinc Alloy | Black Matte Powder Coated |
| 2119-B-5740R-10 | 4 | 5.7 | Zinc Alloy | Black Matte Powder Coated |
| 2119-B-7354F-10 | 7.3 | 5.4 | Zinc Alloy | Black Matte Powder Coated |
| 2119-B-7354R-10 | 5.4 | 7.3 | Zinc Alloy | Black Matte Powder Coated |
| 2119-B-9067F-10 | 9 | 6.7 | Zinc Alloy | Black Matte Powder Coated |
| 2119-B-9067R-10 | 6.7 | 9 | Zinc Alloy | Black Matte Powder Coated |
